A-3W-K

Relé signálové 3V 2A 2c 64,3R
Contact Form: DPDT
Max. Switching Current: 2 A
Coil Voltage: 3VDC
Type: Signal
Coil Resistance: 64,3 Ohm
Coil Power: 140 mW
Max. Switching Power: 62,5VA/30W
Max. Switching Voltage: 125VAC/110VDC
Dielectric Strength (between coil and contacts): 1000VAC
Operate/Release time: 6ms/4ms
Dimensions: 14x9x5mm
Contact Material: Ag alloy + Au plated
Description: miniature
Note: n/a
Series: n/a
